ahlmann AS 210 - Page 110

S200/S201/Z200 12-9
Technical Data (Attachments) 12
12.2.1 Buckets
Bucket type Standard Lightweight Multi-purpose
bucket bucket bucket
Bucket volume m³ 2,1 2,4 1,8
Bucket width mm 2.700 2.700 2.700
Dead weight kg 730 760 840
Loads acc. to ISO 14397
Bulk density t/m³ 1,8 1,5 2,0
Dump load
- frontal kg 7.650 7.600 7.550
- swivelled kg 7.500 7.400 7.300
Payload
- frontal kg 3.825 3.800 3.775
- swivelled kg 3.750 3.700 3.650
A Total length mm 6.850 7.000 6.840
AA4 Max. dump angle ° 100 100
A2 Max. dump angle ° 50 50 50
B Max. dumping distance
at dumping angle 45° mm 2.100 2.170 2.170
G Dumping height at
max. dumping distance
and dumping angle 45° mm 1.200 1.140 1.135
H6 Depth of feed-in mm 70 70 70
H8 Dumping height at max. lifting height
and dumping angle 45° mm 3.120 3.060 3.055
H10 Max. working height mm 5.450 5.530 5.425
J Free lift height mm 3.660 3.660 3.660
LL Dumping distance at max. lifting height
and dumping angle 45° mm 1.010 1.090 1.100
L6 Dumping distance at max. lifting height
and dumping angle 45° mm 1.465 1.545 1.555
RR Max. dumping distance
at dumping angle 45° mm 1.650 1.730 1.720
Multipurpose bucket opened:
D Dumping distance at max. lifting height
and tilted bucket mm - - 1.010
HH13 Max. dumping height
with tilted bucket mm - - 3.965
MM Dumping distance at max. lifting height
and tilted bucket mm - - 560
