S200/S201/Z200 12-11
Technical Data (Attachments) 12
12.2.2 Fork-lift attachment
Tine length 1.600 mm
Tine height 70 mm
Dead weight 340 kg
Perm. payload N acc. to EN 474-3
frontal
- level ground (stability factor 1.25) 5450 kg
- uneven ground (stability factor 1.67) 4100 kg
swivelled
- level ground (stability factor 1.25) 4770 kg
- uneven ground (stability factor 1.67) 3600 kg
Perm. payload N (fork-lift attachment 300 mm above ground)
frontal
- level ground (stability factor 1.25) 6.600 kg
- uneven ground (stability factor 1.67) 4.950 kg
A Total length 7.600 mm
A5 Tilt angle 25°
B Min. reach 900 mm
C Max. reach 1.560 mm
D Reach at max. lifting height 820 mm
G Free lift height at max. reach 1855 mm
H6 Depth of feed-in 110 mm
HH15 Free lift height at max. reach (upper tine edge) 3.830 mm
KK Max. reach 1.110 mm
LL Distance between tyre and payload 1.500 mm
MM Reach at max. lifting height 370 mm
PP Min. free lift height 780 mm
12.2.3 Lifting hook
Perm. payload acc. to DIN EN 474-3
Max. outreach (stability factor 2)
- frontal 2530 kg
- swivelled 1930 kg
Dead weight 240 kg
A Total length 7.085 mm
DD Max. outreach 3.235 mm
HH Max. lifting height 5.225 mm
RR Max. outreach 2.785 mm
