Signs 2
S220/S221/S230/S231/Z200 2-3
1 Symbol: Stay out of the danger zone
2 Symbol: Lashing eyes
3 Symbol: Lifting hook
4 Symbol: Swivelling
5 Sign: » Only for loaders with pipe break protection «
CAUTION!
The lift cylinders’ pipe break protection is disabled when the lifting suspension is
switched on.
Do not switch on the lifting suspension while the fork-lift or lifting hook attachment
is fitted.
6 Symbol: Steering type switching (4-8/3)
rear-wheel/four-wheel steering
7a Sign: Sound power level (sect. 11.17)
7b Sign: In-band accoustic level (sect. 11.17)
8 Sign: free
9 Sign: Lettering “Low-noise construction machine”
10 Symbol: Hydraulic oil tank
11 Sign: Maximum speed
12 Symbol: Open only when the engine is not running
13 Sign: Tyre pressure
14 Sign: Maintenance schedule
15 Sign: CAUTION! - Steering only possible when engine is running!
16 Sign: CAUTION! -Use only rear-wheel steering when driving on public roads.
17 Symbol: Gear shift - 2nd gear
- 1st gear
- Alpha max.
18 Symbol: Hand lever for working hydraulics (4-9/6)
19 Symbol: Ball block valve for working/auxiliary hydraulics closed
20 Symbol: Read and observe the operating instructions before commissioning.
Make sure that all other users have read the safety instructions!
21 Symbol: Fuel tank
22 Machine type label (includes the identification number of the vehicle)
23 Sign: Annual inspection as per UVV
24 Sign: UVV badge
