ahlmann AS 210 User Manual

S200/S201/S210/S211/Z200
10 Diagrams
10-4
Item Designation
i
89 Starter
90 Alternator
91 Battery main switch
92 Batteries
93 Engine shut-off valve
94 Start fuel allowance valve
95 Coolant temperature switch
96 Coolant temperature sensor
97 Oil pressure switch
98 Fan valve
99 Temperature sensors
100 Temperature sensors
101 Fan reversal valve
102 Brake light switch
103 Air condition compressor
104 Reversing buzzer
105 Synchronisation valve
106 Valve, reverse drive direction
107 Valve, forward drive direction
108 Switch: low cooling water
109 Switch: hydraulic oil filter
110 Switch: hydraulic oil temperature
111 Switch: parking brake
112 Tail light, left
113 Tail light, right
114 Switch: service brake failure
115 Auxiliary hydraulics valve: open bucket
116 Auxiliary hydraulics valve: close bucket
117 Alpha max. valve
118 Gear switch valve (only for fast loaders)
119 Differential lock valve
120 Combination valve: pipe break protection / lifting device suspension (option)
121 Reservoir valve, lifting device suspension (option)
122 Memory valve, lifting device suspension (option)
123 Pressure switch, lifting device suspension (option)
124 Four-wheel drive valve (option)
125 Windshield washer motor, front
126 Window washer motor, rear
127 Dip pipe sensor
128 Speed sensor
129 Main headlights, left
130 Main headlights, right
131 Signal horn
132 Quick-change device release valve
133 Bucket arm working lights
134 Bucket arm working lights
135 7-pole socket
NOTE
The bold numbers next to the item numbers in the electric wiring diagram are cross-references to the
respective part in the hydraulic diagram.
