8. Appendix
ANET429-x Users Manual
51
8.2.3 ARINC429-R Interface Connector
For connecting to the external ARINC429 Bus, a female DSUB26 connector is
provided.
The pinout is shown below:
Pin No.
Signal
1
ARINC429 TxRx_True_1
2
ARINC429 TxRx_Comp_1
3
ARINC429 TxRx_True_2
4
ARINC429 TxRx_Comp_2
5
ARINC429 TxRx_True_3
6
ARINC429 TxRx_Comp_3
7
ARINC429 TxRx_True_4
8
ARINC429 TxRx_Comp_4
9
GND
10
ARINC429 TxRx_True_5
11
ARINC429 TxRx_Comp_5
12
ARINC429 TxRx_True_6
13
ARINC429 TxRx_Comp_6
14
ARINC429 TxRx_True_7
15
ARINC429 TxRx_Comp_7
16
ARINC429 TxRx_True_8
17
ARINC429 TxRx_Comp_8
18
GND
19
ARINC429 TxRx_True_9
20
ARINC429 TxRx_Comp_9
21
ARINC429 TxRx_True_10
22
ARINC429 TxRx_Comp_10
23
ARINC429 TxRx_True_11
24
ARINC429 TxRx_Comp_11
25
ARINC429 TxRx_True_12
26
ARINC429 TxRx_Comp_12
Table 8-2 Pinout ARINC429 Interface Connector
APE1553-1/2(-DS) Hardware Manual 5
2.3.2 Trigger, IRIG and General Purpose Discrete-I/O (GPIO) Interface Connector
The Trigger, GPIO and IRIG signals are provided on a High-Density DSUB26 female
connector. The RS232 signals are for maintenance purposes only.
Pin No. Signal
1 RS232 RXD
2 Trigger Output BC, Channel 1
3 Trigger Input BC, Channel 1
4 Trigger Output BC, Channel 2 (APE1553-2 only)
5 Trigger Input BC, Channel 2 (APE1553-2 only)
6 IRIG Input
7 General Purpose Discrete Input/Output 1 (GPIO1)
8 reserved
9 reserved
10 RS232 TXD
11 Trigger Output RT, Channel 1
12 Trigger Input RT, Channel 1
13 Trigger Output RT, Channel 2 (APE1553-2 only)
14 Trigger Input RT, Channel 2 (APE1553-2 only)
15 General Purpose Discrete Input/Output 2 (GPIO2)
16 General Purpose Discrete Input/Output 3 (GPIO3)
17 GND
18 General Purpose Discrete Input/Output 4 (GPIO4)
19 Trigger Output BM, Channel 1
20 Trigger Input BM, Channel 1
21 Trigger Output BM, Channel 2 (APE1553-2 only)
22 Trigger Input BM, Channel 2 (APE1553-2 only)
23 IRIG Output
24 General Purpose Discrete Input/Output 5 (GPIO5)
25 reserved
26 reserved
Table 2.3.2-1: Pinout HD-DSUB26 Frontpanel-Connector
1
10
19
9
18
26
(front view)
26 Pin, High Density DSUB (female)
Figure 2.3.2-1: HD-DSUB26 connector, Pin1
Figure 8-4 ANET429-R Connector
