2.2.2 Buttons and LEDs
2.2.2.1 Ethernet RJ45 connector Status LEDs
On the RJ45 connector two status LEDs are implemented.
Yellow LED: for Link and Activity status
Green LED for the speed detection (10/100MBit)
2.2.2.2 Status Indicator
On top of the ANET429 cover, the transparent AIM Logo is illuminated and indicates the
status from the ANET429 as following:
Power ON/OFF / Normal operation
LED = RED illuminated
Illuminated during power on cycle
LED = BLUE fast pulsing
Fast pulsing blue during ASP / LINUX boot up
LED = BLUE slow pulsing
Slow pulsing blue when the on board OS has been boot up (ready for operation)
LED = RED fast pulsing
Fast pulsing red during ASP / LINUX shutdown (power off) cycle and during re-
boot commanded via the ANET Web Configuration tool
Maintenance / Emergency - Mode (e.g. running an update)
LED = RED fast pulsing
Fast pulsing red during re-boot OS to Maintenance-Mode and during an update
cycle is running
LED = RED slow pulsing:
If OS is in Maintenance-Mode
