8. Appendix
ANET429-x Users Manual
55
8.3 Certificate of Volatility
Model: ANET429
Part-Number: 12E2x -0111
Manufacturer: AIM GmbH
Sasbacher Str. 2
D-79111 Freiburg
Germany
Volatile Memory
Does the item contain volatile memory (i.e., memory whose contents are lost when power is
removed)?
Yes No
Description of used volatile memory:
Type:
DDR2-RAM
Size:
128 MByte
User Modifiable:
Yes
No
Function:
Buffers, Descriptors,
Global RAM
Process to Sanitize:
Power off / on
(Power Cycle)
Type:
LPDDR2-RAM
Size:
256 MByte
User Modifiable:
Yes
No
Function:
ASP Local RAM
Process to Sanitize:
Power off / on
(Power Cycle)
Non-Volatile Memory
Does the item contain non-volatile memory (i.e., memory whose contents are retained when power
is removed)?
Yes No
Description of used non-volatile memory:
Type:
Serial SPI-Flash
Size:
8MByte
User Modifiable:
Yes
No
Function:
FPGA Boot
Process to Sanitize:
erase
Type:
Serial SPI-Flash
Size:
1MByte
User Modifiable:
Yes
No
Function:
BIU Processor Boot
Process to Sanitize:
erase
Type:
NAND Flash
Size:
1GByte
User Modifiable:
Yes
No
Function:
Embedded Linux
Process to Sanitize:
erase
Media
Does the item contain media storage capability (i.e., removable or non-removable disk drives, tape
drives, memory cards, etc.)?
Yes No
Description of used media storage:
Type:
-None-
Size:
-
User Modifiable:
Yes
No
Function:
-
Process to Sanitize:
-
Additional Information:
Test Engineer
Name:
Matthias Lamp
Title:
Date of Certification:
04.07.2016
All operating Data for handling the I/O Protocol will be stored in volatile memory only.
No Transfer data is stored in Non-Volatile Memory. The Non-Volatile Memory only
contains production relevant data for board personalisation, FPGA Logic or Firmware
Code for the on board Microcontroller.
