FS2 v2.1r1 www.aja.com
106
Composite Analog The FS2 composite analog video input/output formats are:
• 525i/59.94 (switchable NTSC 7.5 IRE,
NTSC 0 IRE, or PAL-M)
• 625i/50
Reference • 525i/59.94 analog composite
• 625i/50 analog composite
• Tri-level sync
Computer (VESA)
Formats
The FS2 accepts these computer (VESA) video formats:
• 640x480 (VGA) - 60 Hz
• 800x600 (SVGA) - 60 Hz
• 1024x768 (XGA) - 60 Hz
• 1152x864 - 75 Hz
• 1280x768 (WXGA) - 60 Hz
• 1280x960 - 60 Hz
• 1280x1024 (SXGA) - 60 Hz
• 1600x1200 (UXGA) - 60 Hz
• 1680x1050 (WSXGA+) - 60 Hz
• 1920x1200 (WUXGA) - 60 Hz
Video A/D, D/A Converters
•12 bits
• 2x oversampled (HD)
• 4x oversampled (SD)
Audio
Inputs and Outputs • 8-channel balanced analog I/O, DB-25F 25-pin connector (Tascam pinout)
•16-channel AES/EBU
I/O, DB-25F 25-pin connector
• 16-channel SDI/HD-SDI embedded
Audio Levels Audio levels can be set to:
• +12dBu, +15dBu, +18dBu, +24dBu, (Full Scale Digital)
Interfaces
LAN • 10/100/1000 automatic configuration
• Automatic cable crossover (auto MDI-X)
• Embedded web server
•SNMP
• VTECS™ protocol for Remote Control Panel
