AJA FS2 - LED Indicators

FS2 v2.1r1 www.aja.com
19
NOTE: Menus and parameters are described in detail in Chapter 4.
LED Indicators Indicators on the front panel are multi-state LEDs that light when a condition is present.
They are conveniently arranged in groups to show specific subjects. For example,
indicators for the two video processors are aligned in two columns with 1 and 2 labeling
the tops of the columns.
The indicators and the conditions that cause them to light are as follows:
REMOTE A multicolor LED that indicates the current control mode:
• Green = Local Only (front panel control only)
• Red = Remote Only (remote browser or panel control only)
• Amber = Local + Remote (front panel and remote control both enabled)
VID IN 1/2 (blue) An active video input signal is detected for Channel 1 or 2.
UFC 1/2 (blue The Universal Format Converter has been changed from the default setting for Channel 1
or
2.
PROC AMP 1/2 (blue) The Proc Amp has been changed from the default setting for Channel 1 or Channel 2 (it’s
no
longer at unity).
FMT ERR 1/2 (blue) The selected input and output formats are incompatible for Channel 1 or Channel 2.
REF (blue) The REF connector has an external reference video source applied.
KEYER (blue) Reserved for future use.
Table 1. SELECT and ADJUST Knob Operation Summary
Function Knob Action
Scroll through menus.
Scroll through parameters in a multiparameter menu.
Scroll through numerals or letters in a parameter.
Turn SE
LECT backwards or forward.
Enter edit mode for a menu.
Enter edit mode for a parameter.
Enter edit mode for values, numerals, or letters.
Advance to the next value, numeral, or character to edit.
Turn and stop SELECT on
the item to edit. (For some
multiple parameter menus, push ADJUST so that the
selected parameter blinks.)
Increment/decrement a value. Turn AD
JUST.
Coarse adjust a value. Hold down button and turn AD
JUST.
Reset a value to the factory default value.
Set a number to the default value
(typically zero).
Set a letter to a default value (typically space).
Hold down AD
JUST.
Take (commit) a change to an edited parameter. Automatic after a few seconds for most parameters. For
mu
ltiple field parameters, push ADJUST momentarily to
save.
Abandon (undo) a change before committing. Push SELECT momentarily
.
Take (commit) a special action, such as a preset recall. Push ADJ
UST momentarily.
