FS2 v2.1r1 www.aja.com
89
IP Address IP Address determines the static IP address used by the FS2 for TCP/IP networking.
(Networking is discussed in Chapter 3, Network Connection.) Consult your network
administrator about how to set this value.
Netmask Netmask determines the subnet mask used by the FS2 for TCP/IP networking.
Default Gateway Default Gateway determines the gateway or router used on your LAN for TCP/IP
networking.
Without a properly configured default gateway (whether you have a router/gateway or
no
t), the FS2 will be unable to see other FS2s on the network, although you may still be
able to control this FS2 via a web browser. Also, without a proper gateway defined, the
discovery feature “Available FS2s—Click to Refresh” on the Network web page will not
work correctly and list other FS2s on the network.
Variable If IP Address Type is set to DHCP, the IP address is set automatically by
the network DHCP server and cannot be entered here.
If IP A
ddress Type is set to Static, enter an IP address compatible with
your LAN here. Also enter a netmask and default gateway address
in the following two parameters. Click Apply when you are ready to
apply all three entries to change the FS2's network addressing.
If IP A
ddress Type is set to DHCP and there is a DHCP failure, the IP
address is set to the static IP address. The default static IP address
is 192.168.0.2
Variable Enter a subnet mask compatible with your LAN. This is only needed
for Static IP configurations. The factory default Subnet Mask is
255.255.255.0
If IP A
ddress Type is set to DHCP, the Subnet Mask is set by the DHCP
server and cannot be changed by the user.
Variable Enter a default gateway or router address. This is only needed for
Static IP configurations. The factory Default Gateway is 192.168.0.1.
If IP A
ddress Type is set to DHCP, the Default Gateway is set by the
DHCP server and cannot be changed by the user.
