FS2 v2.1r1 www.aja.com
78
1.0 Audio Input This parameter performs input audio source selection for Audio Processor 1. Multiple
input sources may be present at all the connectors on the FS2 rear panel, but the active
input source routed through the FS2 is the one selected here.
NOTE: If parameter 3 Audio Follow Video is set to On,
the Audio Input selection is independently
remembered for each video input. When Audio Follow Video is Off, audio for each video input
is not remembered and you must manually select the audio source you want. If you have
never manually selected the audio source, the factory default audio selection is used.
AES/EBU (default Selects the AES/EBU digital audio
input (16-ch) as the input
source.
Analog Selects the Analog audio connector (DB25, 8-ch) as the input
so
urce. Input channels 9-16 are set to Mute.
Embed SDI1 Uses the embedded audio from the SDI 1 video input as the input
sour
ce.
Embed SDI2 Uses the embedded audio from the SDI 2 video input as the input
sour
ce.
Embed Fiber1 Uses the embedded audio from the optional Fiber 1 video input as
th
e input source.
Embed Fiber2 Uses the embedded audio from the optional Fiber 2 video input as
th
e input source.
HDMI Uses the embedded audio from the HDMI video input (8-ch) as
t
he input source. Input channels 9-16 are set to Mute.
Dolby Decode Selects the Dolby Decoder output as t
he audio processor input.
Mute Sets all input channels to Mute.
Channel Map For the 16 channels of audio input, selects inputs according to
A
udio Map parameters 1.1 through 1.16. Any of the 16
embedded channels can be mapped to one of the 96 sources.
Stereo Map For the 16 channels of audio input, selec
ts stereo inputs according
to Audio Map parameters 1.17 through 1.24. Any channel pair (8
pair total) can be mapped to 48 different choices.
