FS2 v2.1r1 www.aja.com
50
2.2 IP Address This parameter determines the static IP address used by the FS2 for TCP/IP networking.
Consult your network administrator about how to set this value.
Octet Value Entry
Procedure
Set the octets (numbers between periods) values as follows:
1. Push ADJ
UST momentarily to enter edit mode.
2. Turn SE
LECT to select the octet you want to edit, indicated by blinking.
3. Turn AD
JUST to enter the new value.
• If you need to revert to the previo
us setting (undo changes), push SELECT.
4. Push ADJ
UST momentarily to save and activate the new setting.
• If you want to revert to the de
fault value, hold down ADJUST for 4 seconds.
2.3 Subnet Mask This parameter determines the subnet mask used by the FS2 for TCP/IP networking.
Consult your network administrator about how to set this value.
2.4 Default Gateway This parameter determines the gateway or router used on your LAN for TCP/IP
networking. Consult your network administrator about how to set this value.
Without a properly configured default gateway (whether you have a router/gateway or
no
t), the FS2 will be unable to see other FS2s on the network, although you may still be
able to control this FS2 via a web browser. Also, without a proper gateway defined, the
discovery feature “Available FS2s—Click to Refresh” on the Network web page will fail to
list other FS2s on the network.
3 MAC Address
(view only)
Selecting this parameter allows you to view the FS2 MAC address. The MAC address is a
unique value associated with the FS2’s internal network adapter. MAC addresses are also
known as hardware addresses or physical addresses. MAC addresses uniquely identify an
Ethernet adapter on a LAN.
MAC address format: MM:MM:MM:SS:SS:SS
The value is 12-digit hexadecimal, where the first half identifies the manufacturer and the
se
cond half identifies the unique serial number.
SNMP Menu
Parameters
The following parameters are used to setup the FS2 SNMP (Small Network Management
Protocol) feature.
•4.0 SNMP Enable
IP Address variable If 2.1 is set to DHCP dynamic addressing (default), the IP Address is set
automatically by the network's DHCP server.
If 2.1 is set t
o Static Addr, manually enter an IP address.
If 2.1 is set to DH
CP and there is a DHCP failure, the IP address is set to the
static IP address. The factory default static IP address is 192.168.0.2.
Subnet Mask variable Enter a subnet mask compatible with your LAN. This is only needed
for Static IP configurations.
If 2.1 is set to DHCP, the Subnet Mask is set by the DHCP server and
cann
ot be changed by the user.
If 2.1 is set to De
fault Addr, the default Subnet Mask is 255.255.255.0
Gateway Address variable Enter the address of the gateway or router used to connect the
FS2 to the network. Default: 192.168.0.1
