and influenced by the composite signal on the Component Y/G input. For example, in the
VIDEO menu, setting Video1 Input to the value of Component, switches the composite
signal on the Component Y/G input into the Video 1 Processor.
2 Component Out
Format
This parameter configures the format of the Component video output for SMPTE, Beta,
RGB, or Composite. Selecting Composite (Y) programs the Component (Y/G) output to
deliver a composite signal. In this case, all parameters set to a value of Component are
subject to and influenced by the composite signal on the Y/G Component output. For
example, in the OUTPUT menu, Component Out, selecting Processor2 will switch the
composite signal from Video Processor 2 to the Component Y/G connector.
3 Analog Audio Std This parameter sets the Analog Audio Input and Output levels of the FS2 with reference to
full scale digital (0 dBFS). Selections range from consumer levels (+12 dBu) to SMPTE
professional (+24 dBu).
NOTE: See Chapter 3 FS2 Audio Level Choices—Pro or Consumer regarding audio levels.
4 SDI1 3G Detect This parameter configures 3G operation of the SDI 1 video input.
In Au
to Detect mode, the hardware looks for SMPTE 352 Payload ID ANC data on the
video inputs to determine whether there are two independent 1080i signals (Dual
Stream) or a single 1080p50/60 signal. If there is no SMPTE 352 data, the default is to
assume 1080p50/60 (single), but you can manually instruct the FS2 to always assume
either 1080p50/60 or Dual Stream by selecting one of those choices.
SMPTE YPbPr (default)
Beta YPbPr
Composite (Y)
Configure the Component Video Input source as SMPTE YPbPr.
This is the default for HD component video.
Configure the Component Video Input source as Beta YPbPr
(
standard definition).
Configure the Component Video Input source as composite,
pr
oviding a second composite input (requires version 1.1
firmware).
SMPTE YPbPr (default)
Beta YPbPr
RGB
Composite (Y)
Configure the Component Video Output as SMPTE YPbPr. This is
the default for HD component video.
Configure the Component Video Output as Beta YPbPr (SD).
Configure the Component Video Output as RGB.
Configure the Component Video Output source as composite,
pr
oviding a second composite output (requires version 1.1
firmware).
+24 dBu (default)
+18 dBu
+15 dBu
+12 dBu
Select +24 dBu as the expected analog audio level.
Select
+18 dBu as the expected analog audio level.
Select
+15 dBu as the expected analog audio level.
Select
+12 dBu as the expected analog audio level.
(Above settings correspond to maximum amplitude–0 dBFS)
Auto Detect (default)
1080p50/60
Dual Stream
Automatically detects presence of 1080p50/60 or Dual
Stream video.
Configures the SDI1 input for 1080p50/60 (single) video.
Configures SDI 1 for Dual Stream 3G video (uses SDI 1
a
nd SDI 2 in Input Crosspoint matrix).
