STATUS Menu Group
The Status Menu Group contains a series of Status display pages that you can scroll using
the SELECT knob. The various Status pages are actually just displays, not menus, since
they don’t include menu numbers or editable values. The ADJUST knob doesn’t affect the
Status display pages.
When you press the ST
ATUS button, the display shows the first menu unless there is an
active alarm. If an alarm is active, the relevant alarm status page is displayed first. If more
than one alarm is active, the highest priority alarm page is displayed first.
NOTE: When displaying video format status, the following c
onvention differentiates between SMPTE
video formats (broadcast) and computer (VESA/DVI) formats (non-broadcast formats
originating from a computer DVI signal). The SMPTE formats are shown as height (in lines),
scan-format (progressive or interlaced), and frame-rate, such as 1080i59, for example. the
VESA formats are shown as a size only, with an x in the middle, such as 640x480, for example.
S.1 I/O Status This menu shows the current primary settings for Processors 1 and 2.
S.2 Vid1 Format
Status
This menu shows the current primary settings for Processor 1.
S.3 Vid1 Format
Alarm Status
This menu shows the Processor 1 alarm status. Absence of alarm shows as OK. If
selections are incompatible, the status of the affected signal shows incompat.
Display Description
IN1 Sel Video Format
OUT1 Sel Video Audio
IN2 Sel Video Format
OUT2 Sel Video Audio
Processor 1 selected video input and detected format.
Processor 1 video output format and selected audio input.
Processor 2 selected video input and detected format.
Processor 2 video output format and selected audio input.
Display Description
VID1 Input Source Format
BKGD Backgd Source
GEN Genlock Source Format
OUT Format
Selected Processor 1 video input source and format.
Selected Background video source.
Selected Genlock source and format.
Selected Processor 1 output format.
Display Description
VID1 Input Source Status
BKGD Backgd Source Status
GEN Genlock Source Status
OUT Status
Selected Processor 1 video input source alarm status.
Selected Background video source alarm status.
Selected Genlock source alarm status.
Selected Processor 1 output format/alarm status.
