FS2 v2.1r1 www.aja.com
107
RS-422 • DB-15F: Reserved for future use.
GPI • DB-15F: single connector provides four inputs and four outputs. See Appendix B for a
co
nnector pinout and GPI specifications.
Physical
Dimensions • Width: 17.5 inches (44.45cm); 19 inches (48.26 cm) including rack ears
• Depth: 16 inches (40.65 cm), including knobs and connectors that extend beyond the
frame
• Height: 1RU, 1.75 inches (4.44cm)
Weight • 7.85 pounds, 3.56 kilograms
Temp erat ure • Operating temperature range: 0–40 degrees C
• Cooled via two internal fans and side vents.
Power • Voltage: 100-240 VAC
• Power Consumption: 55W (80W maximum)
• Two independent power supplies, fully redundant, diode isolated.
