FS2 v2.1r1 www.aja.com
18
•Video Processor Input Source and Background Fill selections
• Video Processor Output Format and Mode
• Loss of Input
• Video Processor Up, Down, Aspect, Edge
, and Custom Conversions
• Video Processor Matte Adjustments
• Video Processor H and V timing
• Video Processor Proc Amp, Color Corrector, and Legalizer
• AFD embedding, input scan format (i or p), and caption translation
• Video Processor Test Patterns
• Freeze Output
AUDIO 1 and 2 Displays the Audio 1 Menu Group, which allows you to set Audio Processor 1 selections
an
d adjustments:
• Audio Processor input selection, output embedding, and Audio Follow Video (AFV)
•Audio Signal Gene
rator Selection
• Audio1 channel and stereo mapping
• Audio1 level, phase, and delay adjustments
Control Knobs These are the general rules of SELECT and ADJUST knob operation:
SELECT Turning the SELECT knob performs these actions:
•Turn SE
LECT in either direction to scroll through the menus.
• Stop on a menu to enter that
menu for editing.
•Turn SE
LECT within a menu to scroll through multiple parameters.
• Pause on a parameter to select it for editing. For
multiple fields in a parameter, use
SELECT to move through the fields (after pressing Adjust to enter field editing mode).
•Push SEL
ECT momentarily to undo and restore the previous setting.
ADJUST Turning the ADJUST knob performs these actions:
•Turn AD
JUST to change the values of a selected parameter.
• In most cases, leaving a value in place fo
r a moment sets that value.
• To perform special actions, such as recalling a register, push the knob to confirm
the
displayed value. Display line 4 indicates such special actions.
• Some parameters having multiple fields, such as IP Address require you to push the
ADJUST kno
b to select a field, and push again to save changes.
• Hold down the knob to reset a
value to the factory default; for multiple field values, all
fields are reset to the default.
