Example of a Serial
Recall
The advantage of using GPI IN Response with presets is that you can trigger a series or
even a looping series of preset recalls. For example, suppose GPI IN 1 Response in Preset 1
is set to Preset 2, and GPI IN Response in Preset 2 is set to Preset 1. Triggering the GPI will
toggle between the two presets.
Example of an
Unintended Recall
Suppose you trigger GPI IN 1 while the current GPI IN 1 Response parameter is set to
Preset 1. This recalls Preset 1 as expected. However, suppose Preset 1 contains a stored
GPI IN
1 Response setting of No Action. If you trigger GPI IN 1 later, expecting to recall
Preset 1 again, the FS2 instead performs No Action. To prevent unexpected changes in
the GPI IN Response parameters, set these parameters as desired before storing presets; in
the example, set GPI IN 1 to Preset 1 before you store Preset 1.
CONFIG Menu Group
The CONFIG Menu Group includes parameters for setting up the FS2’s network, system
name, SNMP, alarm, and screen saver configurations.
1 System Name This parameter defines a unique name for the FS2. This same name is used both when
displaying systems via the web interface and when displaying the FS2’s screen saver.
Name Entry Procedure Set the name as follows:
1. Push ADJ
UST momentarily to enter character editing mode.
2. Turn SE
LECT to advance the blinking cursor to each character.
3. Turn AD
JUST to scroll through the choices for each character. These characters are
allowed: A through Z (uppercase), a through z (lowercase), numerals, hyphen (-),
period (.), and space (blank). Leave the desired character selected and advance to the
next one.
4. Push ADJ
UST to save and activate the name after all characters are defined.
• To abandon changes before saving, push SELECT.
• To return to the default name a
t any time, hold down ADJUST.
NOTE: To eliminate trailing characters to shorten an existing system name, overwrite them with a
hyp
hen (-) or space.
2.1 IP Config This parameter determines the type of TCP/IP network configuration used by the FS2.
Consult your network administrator about how to set this value.
Variable Set the system name, up to 20 characters. Default: aja-fs2
DHCP (default)
Static Addr
Select automatic IP address assignment from the LAN DHCP server. If
the FS2 cannot find a DHCP server, it fails over to the static IP address.
Assign a static IP address manually (using
parameters 2.2, 2.3, and 2.4).
The factory default static IP a
ddress: 192.168.0.2
