AJA FS2 - Custom Aspect; Custom Bottom Crop; Custom H Position; Custom Left Crop

FS2 v2.1r1 www.aja.com
71
13.0 Custom Size/Pos This parameter turns custom image settings 13.1–13.8 On or Off.
On the front panel, when Hide Inactive is on, the Custom co
ntrols 13.1–13.8 are only
displayed when Custom Size/Pos is On. When Custom Size/Pos is Off, parameters 13.1–13.8
are skipped in the menu system, and the UFC hardware is programmed for unity.
This menu is also not displayed when Active F
ormat Description (AFD) is in control of the
Conversion Mode. While downconverting, with Downconvert Mode set to Auto AFD, any
values assigned for Custom Size/Pos parameters are ignored, and the menus are hidden.
13.1 Custom Size This parameter changes the H and V size of the output picture by the specified
percentage (%) while maintaining the current aspect ratio.
13.2 Custom Aspect This parameter changes the H/V aspect ratio of the output picture while maintaining the
current V size (Aspect < 0) or H size (Aspect > 0).
13.3 Custom H Position This parameter changes the H position of the output picture.
13.4 Custom V Position This parameter changes the V position of the output picture.
13.5 Custom Left Crop This parameter changes the Left picture crop position.
13.6 Custom Right Crop This parameter changes the Right picture crop position.
13.7 Custom Top Crop This parameter changes the Top picture crop position.
13.8 Custom Bottom
Crop
This parameter changes the bottom picture crop position.
Off (default)
On
Sets this parameter and related custom size/pos parameters to off.
Enables this parameter and related custom size/position
paramet
ers.
100% (default)
10% to 200%
Maintains 100% picture size for the selected format.
Enables changing the picture size.
0.000 (default)
-0.500 to +0.500
Maintains the normal 100% aspect ratio for the selected format.
Enables changing the aspect ratio.
0% (default)
-100% to +100%
Maintains the normal horizontal position of the selected format.
Enables changing the horizontal position.
0% (default)
-100% to +100%
Maintains the normal 100% vertical position of the selected format.
Enables changing the vertical position.
100% (default)
+10.0% to +100.0%
Maintains the normal left side position of the selected format.
Enables changing the left side position.
100% (default)
+10.0% to +100.0%
Maintains the normal right side position of the selected format.
Enables changing the right side position.
100% (default)
+10.0% to +100.0%
Maintains the normal top position of the selected format.
Enables changing the top position.
100% (default)
+10.0% to +100.0%
Maintains the normal bottom position of the selected format.
Enables changing the bottom position.
