AJA FS2 - Caption Status; Output Status; Power;Temp Alarm; VID 2 Format Alarm Status

FS2 v2.1r1 www.aja.com
45
S.4 Vid2 Format
Status
This menu shows the current primary settings for Processor 2.
S.5 Vid 2 Format
Alarm Status
This menu shows the Processor 2 alarm status. Absence of alarm shows as OK. If
selections are incompatible, the status of the affected signal shows incompat.
S.6 Output Status This menu shows the video source selected for each of the video outputs.
S.7 Power/Temp
Alarm
This menu shows the power supply status of the FS2 and the temperature status. If a
power supply is unplugged, the display top line indicates PS OFF or PS Error.
S.8 Caption Status This menu shows what type of closed caption data is selected and whether closed
caption data is present on the selected video input.
Display Description
VID2 Input Source Format
BKGD Backgd Source
GEN Genlock Source Format
OUT Format
Selected Processor 2 video input source and format.
Selected Background video source.
Selected Genlock source and format.
Selected Processor 2 output format.
Display Description
VID2 Input Source Status
BKGD Backgd Source Status
GEN Genlock Source Status
OUT Status
Selected Processor 2 video input source alarm status.
Selected Background video source alarm status.
Selected Genlock source alarm status.
Selected Processor 2 outpu
t format/alarm status.
Display Description
SDI1 Selected Video Processor
SDI2 Selected Video Processor
Fiber1 Selected Video Processor
Fiber2 Selected Video Processor
HDMI Selected Video Processor
Cmpn Selected Video Processor
Cmpn Selected Video Processor
Selected Processor feeding the SDI 1 output.
Selected Processor feeding the SDI 2 output.
Selected Processor feeding the Fiber 1 output.
Selected Processor feeding the Fiber 2 output.
Selected Processor feeding the HDMI output.
Selected Processor feeding the Component output.
Selected Processor feeding the Composite output.
Display Description
PS1 Alarm Status
PS2 Alarm Status
TmpAlarm Status
Displays the state of the PS1 power supply (OK or ERROR).
Displays the state of the PS 2 power supply (OK or ERROR).
Displays a temperature alarm if the FS2 overheats.
Display Description
VID1CC Caption Type & Presence
ViD2CC Caption Type & Presence
Processor 1 selected caption type (SD/HD/Invalid) and
presence (Detected/Not detected/Pass through).
Processor 2 selected caption
type (SD/HD/Invalid) and
presence (detected/not detected/Pass through).
