To perform a global reset:
1. Go to the Pre
sets screen.
2. Click on the Rec
all button in the Factory Preset row.
User preferences, network settings, and existing Presets are not affected by recalling the
Fa
ctory Preset.
Clicking on the down arrow next to each parameter displays a drop-down list of available
selec
tions.
Drop Down
Parameter
Operation
Most FS2 parameters available on the browser are selected from a drop-down list. The
currently active parameter is displayed. Click on the down arrow symbol next to the
parameter to display the list and select an alternative value. The FS2 will immediately
operate with the new setting.
Slider Operation Some screens contain slider controls for setting values. To set a value, you can click on a
slider to select it and then use the mouse to drag the slider to the position you desire. For
fine tuning, while the slider is selected (highlighted by a blue border), use the keyboard
left and right arrow keys to change the value one unit at a time. After setting a slider's
position, click on the page's background area (blue highlight turns off) to ensure the
change is confirmed and saved.
Video Format
Display
When displaying video format status, the following convention differentiates between
SMPTE video formats (broadcast) and VESA formats (non-broadcast formats originating
from a computer DVI signal). The SMPTE formats are shown as height (in lines), scan-
format (progressive or interlaced), and frame-rate, such as 1080i59, for example. the VESA
formats are shown as a size only, with an x in the middle, such as 640x480, for example.
Screen Descriptions
Now that you have had an introduction to how the FS2 browser works and how to
navigate the screens, each screen and its settings are described in detail. The screens are
described in the order listed on main screen (click to jump):
• “Network Pane and Network Configuration Screen” on page 88
• “Alarm Configuration Screen” on page 90
• “Status Screen” on page 90
• “System Screen” on page 92
• “Config Screen” on page 93
• “Presets Screen” on page 95
• “Output Screen” on page 96
• “Video 1 & 2 Screens” on page 97
• “Audio 1 and 2 Screens” on page 98
• “Remote Screen” on page 99
• “Firmware Screen” on page 100
