• Hold down a button (turns blue) to make coarse adjustments using the Adjust knob.
Release the button to make fine adjustments.
The following text briefly lists the func
tions accessed by each pushbutton:
STATUS Displays the Status Menu Group, which shows current machine status and error
conditio
ns:
• Video 1, Video 2, and Caption status
• Reference and Genlock status
•Output Status
• Power and Temperature status
•System Name display
•Alarms
REMOTE Displays the Remote Menu Group, which lets you select how to control the FS2:
• Control by local front panel, remote devices,
or local and remote
• GPI input and output behavior
CONFIG Displays the Config Menu Group, which lets y
ou configure the FS2 for your environment:
• System Name setting
• IP and SNMP settings, MAC address
•Alarm control
• Hidden Menus and Display i
ntensity (brightness)
• System serial number and software version
•System reboot
PRESET Displays the Reg Menu Group, which accesses the memory registers:
• Store, Recall, and edit the names of Presets
• Factory Preset (defaults)
SYSTEM Displays the System Menu Group, which lets you change or enable FS2 video and audio
input and syst
em functions:
• Video input format settings, including 3G
setup
• Audio input format an
d sample rate conversion settings
• Genlock reference source selection
• Frame rate selection and NTSC standard (North America/Japan)
• Input downconversion setting (HD to SD)
• HDMI RGB Range
OUTPUT Displays the Output Menu Group, which selec
ts output sources:
• Composite downconversion
•Video output selections
• Audio output selections
• 3 G output configuration
• HDMI video and audio configuration
VIDEO 1 and 2 Displays the Menu Groups that access Video P
rocessor video input, format, and
conversion selections and adjustments (separate buttons access Video Processor 1 and
Video Processor 2):
