114 Version 1.21
EDIT PROGRAM
s5000
/
s6000
FILTER MODE Here you can select from one of the 26 different resonant filter types.
These are:
2-POLE LP
This is a 12dB/Octave lowpass filter with resonance.
4-POLE LP
This offers a 24dB/Octave lowpass filter with
resonance. This does the same as the 12dB/Octave
filter except that the roll-off slope is steeper. Thus
high frequencies are attenuated more dramatically
giving what some people refer to as a ‘punchier’sound
compared with the slightly ‘fizzier’ sound of the 2-
POLE lowpass filter.
2-POLE LP+
This is another 12dB/Octave lowpass filter but with
enhanced resonance.
2-POLE BP
This is a resonant bandpass filter with a 6dB/Octave
roll-off slope either side of the band.
4-POLE BP
This is a resonant bandpass filter with a 12dB roll-off
slope either side of the band. This has a similar effect
to the 2-POLE bandpass filter but its steeper rolloff
attenuates the harmonics more profoundly.
