s5000 / s6000 EDIT PROGRAM
2-POLE BP+
This is a bandpass filter with a 6dB/Octave roll-off
slope either side of the band but with enhanced
resonance.
1-POLE HP
A 6dB/Octave highpass with resonance. This allows
high frequency unaffected but attenuates low
frequency harmonics as the cutoff frequency is raised
from 0 to 100.
2-POLE HP
A 12dB/Octave resonant highpass filter similar to the
1-POLE HP but with a steeper roll-off.
1-POLE HP+
This offers a 12dB/Octave highpass filter but with
enhanced resonance.
LO<>HI A resonant filter that is lowpass at the lower end of
the frequency spectrum and highpass at the upper
end.
LO<>BAND A resonant filter that is lowpass at the lower end of
the frequency spectrum and bandpass at the upper
end.
BAND<>HI A resonant filter that is bandpass at the lower end of
the frequency range and highpass at the top end.

Akai S5000 Specifications

General

Type	Sampler
Polyphony	64 voices
Sampling Rate	44.1kHz
Bit Depth	16-bit
MIDI	In/Out/Thru
Operating System	Akai OS
Memory	Up to 256 MB
Storage	Internal hard drive, SCSI
Outputs	8 individual outputs
Filters	Multi-mode resonant filters
Effects	Optional effects board
Formats	Akai S1000/S3000, WAV, AIFF
Inputs/Outputs	SCSI
Display	LCD
