8H10D; 6H3D5D; 6H8D; 8HN; 8HR; RAW.
Wiegand Card Reader Mode: set the wiegand data transmission
format among three options: “ Wiegand 26”, “ Wiegand 34”,
“ Wiegand 58”. The transmission format should be identical
between the door phone and the device to be integrated.
Wiegand Transfer Mode: set the Transfer mode between “Input”
or “ Output” if the door phone is used as a receiver then set it as
“ Input” for the door phone and vice versa.
Wiegand Input Data Order：set the Wiegand input data sequence
between “ Normal” and “Reversed” if you select “ Reversed” then
the input card number will be reversed an vice versa.
Wiegand Output Data Order: set the Wiegand output data
sequence between “ Normal” and “Reversed” if you select
“ Reversed” then the input card number will be reversed an vice
versa.
Wiegand Output CRC: Tick to enable the parity check function to
ensure that signal-based data can be transmitted correctly
