Akuvox E16 Series User Manual

AKUVOX SMART INTERCOM www.akuvox.com
15
cover, connecting them to the
corresponding interface of the main
board. And then Select a suitable size
rubber plug to push all the cables into
the back cover. Fix cable locking plate to
the back cover with two M2.5x6 .
5
Fasten the back cover with four M2.5x6
screws.
6
Hang the device on to the square hanger
on the wall mounting bracket, pull
down the device to make it fall
completely on to the square hanger on
the wall-mounting bracket, then use
the Allen Wrench attached with to
tighten the device with two M3x6
screws.
