Features
Page 16 7210 SAS-D Installation Guide
Features
The 7210 SAS-D includes the following features:
Wire speed, non-blocking, service-aware Ethernet switch
6 100/1000 fiber-optic SFP ports and 4 10/100/1000 Base-T copper ports
Powered by SR OS for feature-rich Carrier Ethernet VPN services
Per-service quality of service (QoS) with up to eight levels of class-based queuing per port
Per-service OAM toolkit with IEEE 802.1ag, IEEE 802.3ah and local service mirroring
Ethernet features include IEEE 802.1Q and QinQ (stacked VLAN IDs)
Dual homed connections uplinks to separate aggregation devices
Flexible deployment options with support for mesh and ring topologies
MEF 9 and MEF 14 compliant platform
Managed by the 5620 SAM
Supports intergrated AC or DC power supply.
The chassis does not use a fan for cooling.
7210 SAS-D ETR variant supports the following, in addition to the above features:
Supports extended temperature range (i.e. -40º C to 65º C) of operation
Supports stratum-3 oscillator onboard, allowing for support of SyncE and 1588v2
Supports an optional backup power supply for all the power supply options supported with
ETR variant.
Note: 7210 SAS-D ETR hardware is capable of supporting Synchronous Ethernet and 1558v2.
Please check the release notes for software support.
