Installing Your Switch
Page 44 7210 SAS-D Installation Guide
Step 2 (Rear view) Assemble and secure the brackets to the switch and the external
power module using the screws provided in the External Power Supply
Mounting Kit. See Figure 21.
Figure 21: Attaching the External Power to the Chassis Using the Mounting Kit (Rear View)
Step 3 Connect the external power module’s power cable to the switch chassis. See
Figure 22 on page 44.
Figure 22: Connecting the Power Cable from the External Power Module to the Chassis
7210SASdc 0011
7210SASdc_0012
2
1
3
