Alcatel-Lucent 7210 SAS-D - Hardware Description; AC Chassis; Figure 5: 7210 SAS-D AC Chassis Front Panel; Figure 6: 7210 SAS-D ETR AC Chassis Front Panel

Hardware Description
Page 18 7210 SAS-D Installation Guide
Hardware Description
The chassis is available with either an AC power module or DC power module, as shown in the
following illustrations.
AC Chassis
Figure 5: 7210 SAS-D AC Chassis Front Panel
Figure 6: 7210 SAS-D ETR AC Chassis Front Panel
7210SASac_0001A
5 63
4
12
7
7210SASac_0001A
5 63
4
12
7
