Alcatel-Lucent 7210 SAS M - Figure 4: Bootstrap Process - System Initialization - Part II-B

Configuration and Image Loading
Page 98 7210 SAS M, X Basic System Configuration Guide
Figure 4: Bootstrap Process - System Initialization - Part II-B
OSSG284
User Login
Successful?
Retry User Login
Revert To Old BOF
Manual
Mode
Restart
Ctrl-D
R
No
Set Bootflag To
NORMAL_BOOT
Yes
Yes
Yes
Save BOF
Successful?
No
Old BOF
Present?
No
Restart
R B
M
Provision The BOF Parameters (Few Are Mentioned
Below) (Secondary/Tertiary Parameters Are Optional)
Image And Config Path (Primary/Secondary/Tertiary),
Safe-boot IP, UplinkA (Port, Vlan, IP/Mask, Static-route),
UplinkB (Port, Vlan, IP/Mask, Static-route), Persist.
If the IP information needs to be obtained from
DHCP server, IP Address shall be configured
as 0 instead of specifying any IP Address.
DHCP server should grant IP address/mask
and the GW.
