Alcatel-Lucent 7705 SAR-A - T1;E1 Port Pinouts

Pinout Assignments
7705 SAR-A Chassis Installation Guide 131
T1/E1 Port Pinouts
Table 35 specifies the T1/E1 port pinout assignments.
Table 35: T1/E1 Port Pinouts—RJ-45 Female
Pin Signal Description
1 R Receive – Ring
2 T Receive – Tip
3 — Not connected
4 R1 Transmit – Ring
5 T1 Transmit – Tip
6 — Not connected
7 — Not connected
8 — Not connected
