OmniSwitch 6560 Hardware Users Guide December 2019 page 1-1
1 OmniSwitch 6560
Refer to the information below for OmniSwitch 6560 models and components.
Model Number Description
OS6560-P24Z8 Fixed-configuration chassis in a 1U form factor with:
• 16 - RJ45 10/100/1000 Base-T PoE ports (802.3at)
• 8 - RJ45 100/1G/2.5G BaseT PoE ports (802.3bt)
• 2 - SFP+ 1G/10G ports
OS6560-P24Z24 Fixed-configuration chassis in a 1U form factor with:
• 24 - RJ45 100/1G/2.5G BaseT PoE ports (802.3bt)
• 4 - SFP+ 1G/10G ports
• 2 - 20G QSFP+ VFL ports
OS6560-P48Z16 Fixed-configuration chassis in a 1U form factor with:
• 32 - RJ45 10/100/1000 Base-T PoE ports (802.3at)
• 16 - RJ45 100/1G/2.5G BaseT PoE ports (802.3bt)
• 4 - SFP+ 1G/10G ports
• 2 - 20G QSFP+ VFL ports
OS6560-24Z8 Fixed-configuration chassis in a 1U form factor with:
• 16 - RJ45 10/100/1000 Base-T ports
• 8 - RJ45 100/1G/2.5G BaseT ports
• 2 - SFP+ 1G/10G ports
OS6560-24Z24 Fixed-configuration chassis in a 1U form factor with:
• 24 - RJ45 100/1G/2.5G BaseT ports
• 4 - SFP+ 1G/10G ports
• 2 - 20G QSFP+ VFL ports
OS6560-24X4 Fixed-configuration chassis in a 1U form factor with:
• 24 - RJ45 10/100/1000 Base-T ports
• 2 - SFP 1G ports
• 4 - SFP+ 1G/10G ports
OS6560-P24X4 Fixed-configuration chassis in a 1U form factor with:
• 24 - RJ45 10/100/1000 Base-T PoE ports (802.3at)
• 2 - SFP 1G ports
• 4 - SFP+ 1G/10G ports
OS6560-48X4 Fixed-configuration chassis in a 1U form factor with:
• 48 - RJ45 10/100/1000 Base-T ports
• 2 - SFP 1G ports
• 2 - SFP+ 1G/10G ports
• 2 - SFP+ 10G ports
