Getting Started Connections and Cabling
OmniSwitch 6560 Hardware Users Guide December 2019 page 2-5
Connections and Cabling
Once your switch is properly installed, you should connect all network and management cables required for
your network applications. Connections may include:
Console connector
Cables to NIs or transceivers
Network Cable Installation Warning
Never install exposed network cables outdoors. Install network cables per manufacturer requirements.
Serial Connection to the Console Port
The console port provides a serial connection to the switch is required when logging into the switch for the
first time. By default, this connector provides a DCE console connection.
Serial Connection Default Settings
For information on modifying these settings, refer to the OmniSwitch 6560 Switch
Management Guide.
baud rate 9600
parity none
data bits (word size) 8
stop bits 1
