OmniSwitch 6560 Chassis Details Chassis and Power Supplies
page 3-20 OmniSwitch 6560 Hardware Users Guide December 2019
OS6560-X10
OS6560-X10 Front Panel
CLASS 1 M LASER CAUTION. CAUTION - CLASS 1 M LASER RADIATION WHEN OPEN.
DO NOT VIEW DIRECTLY WITH OPTICAL INSTRUMENTS
OS6560-X10 Rear Panel
Item Description
A
Virtual Chassis ID LED
B
Status LEDs
C
Console port
D
USB port
E
(1-8) SFP+ (1G/10G) ports
F
(9-10) 20G QSFP+ VFL ports
Item Description
A
Chassis Grounding Lug
B
Fans
C
Internal Power Supply
D
Modular Power Supply
D
F
E
A B
C
BPS
A
B
C D
