PS Side DDR4 DRAM pin assignment:
Signal Name
Pin Name
Pin Number
PS_DDR4_DQS0_P
PS_DDR_DQS_P0_504
AF21
PS_DDR4_DQS0_N
PS_DDR_DQS_N0_504
AG21
PS_DDR4_DQS1_P
PS_DDR_DQS_P1_504
AF23
PS_DDR4_DQS1_N
PS_DDR_DQS_N1_504
AG23
PS_DDR4_DQS2_P
PS_DDR_DQS_P2_504
AF25
PS_DDR4_DQS2_N
PS_DDR_DQS_N2_504
AF26
PS_DDR4_DQS3_P
PS_DDR_DQS_P3_504
AE27
PS_DDR4_DQS3_N
PS_DDR_DQS_N3_504
AF27
PS_DDR4_DQS4_P
PS_DDR_DQS_P4_504
N23
PS_DDR4_DQS4_N
PS_DDR_DQS_N4_504
M23
PS_DDR4_DQS5_P
PS_DDR_DQS_P5_504
L23
PS_DDR4_DQS5_N
PS_DDR_DQS_N5_504
K23
PS_DDR4_DQS6_P
PS_DDR_DQS_P6_504
N26
PS_DDR4_DQS6_N
PS_DDR_DQS_N6_504
N27
PS_DDR4_DQS7_P
PS_DDR_DQS_P7_504
J26
PS_DDR4_DQS7_N
PS_DDR_DQS_N7_504
J27
PS_DDR4_DQ0
PS_DDR_DQ0_504
AD21
PS_DDR4_DQ1
PS_DDR_DQ1_504
AE20
PS_DDR4_DQ2
PS_DDR_DQ2_504
AD20
PS_DDR4_DQ3
PS_DDR_DQ3_504
AF20
PS_DDR4_DQ4
PS_DDR_DQ4_504
AH21
PS_DDR4_DQ5
PS_DDR_DQ5_504
AH20
PS_DDR4_DQ6
PS_DDR_DQ6_504
AH19
PS_DDR4_DQ7
PS_DDR_DQ7_504
AG19
PS_DDR4_DQ8
PS_DDR_DQ8_504
AF22
PS_DDR4_DQ9
PS_DDR_DQ9_504
AH22
PS_DDR4_DQ10
PS_DDR_DQ10_504
AE22
PS_DDR4_DQ11
PS_DDR_DQ11_504
AD22
PS_DDR4_DQ12
PS_DDR_DQ12_504
AH23
PS_DDR4_DQ13
PS_DDR_DQ13_504
AH24
PS_DDR4_DQ14
PS_DDR_DQ14_504
AE24
PS_DDR4_DQ15
PS_DDR_DQ15_504
AG24
