Allen-Bradley ControlLogix Reference Manual

Interpret the Attribute Tables
Chapter 3
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 101
Attr. ID Access
Rule
Tag Attribute Name B E F P V T C/D Conditional
Implementation
1466 Set Feedback 2 Cycle Resolution - R - R R R Yes
E; Not Linear Displacement
Transducer (feedback type)
1471 Set Feedback 2 Data Code - O - O O O Yes
E; Digital Parallel (feedback
type),SSI (feedback type)
1470 Set Feedback 2 Data Length - O - O O O Yes
E; Digital Parallel (feedback
type),SSI (feedback type)
1469 Set Feedback 2 Length - R - R R R Yes E; Linear Absolute Only
2450 Set Feedback 2 Loss Action - O - O O O Yes E
1464 Set Feedback 2 Polarity - O - O O O Yes E
1475 Set Feedback 2 Resolver Cable Balance - O - O O O Yes E; Resolver (feedback type)
1474 Set Feedback 2 Resolver Excitation Frequency - O - O O O Yes E; Resolver (feedback type)
1473 Set Feedback 2 Resolver Excitation Voltage - O - O O O Yes E; Resolver (feedback type)
1472 Set Feedback 2 Resolver Transformer Ratio - O - O O O Yes E; Resolver (feedback type)
1451 Get Feedback 2 Serial Number - - - O O O Yes E
1465 Set Feedback 2 Startup Method - R - R R R Yes E; Optional Enumeration
1468 Set Feedback 2 Turns - R - R R R Yes E; Rotary Absolute Only
1463 Set Feedback 2 Type - R - R R R Yes E; Optional Enumeration
1461 Set Feedback 2 Unit - R - R R R Yes E
1484 Set Feedback 2 Velocity Filter Bandwidth - O - O O O Yes E
2453 Set Feedback 2 Velocity Filter Taps - O - O O O Yes E
250 Set Feedback Commutation Aligned - - - O O O Yes E; PM Motor only,
Optional Enumeration
31 Set Feedback Configuration R R R R R R Optional Enumeration
708 Set Feedback Data Loss User Limit - O O O O O Yes E
42 Set* Feedback Mode - R R R R R Yes Derived - Fdbk Config
706 Set Feedback Noise User Limit - O O O O O Yes E
707 Set Feedback Signal Loss User Limit - O O O O O Yes E
44 Set Feedback Unit Ratio - - - O O - Yes E
871 Set Flux Braking Enable - - O O O O Yes Ind Motor only
528 Get T Flux Current Error - - - O O O Yes
530 Get T Flux Current Feedback - - - O O O Yes
525 Get T Flux Current Reference - - - O O O Yes
557 Set Flux Integral Time Constant - - - O O O Yes
556 Set Flux Loop Bandwidth - - - O O O Yes
558 Set Flux Up Control - - O O O O Yes Ind Motor only,
Optional Enumeration
559 Set Flux Up Time - - O O O O Yes Ind Motor only
380 Set Flying Start Enable - - O - O - Yes
381 Set Flying Start Method - - O - O - Yes V29
570 Set Frequency Control Method - - R - - - Yes Optional Enumeration
498 Set Friction Compensation Sliding - - - O O O Yes

Allen-Bradley ControlLogix Specifications

General

Communication	EtherNet/IP, ControlNet, DeviceNet, DH+
I/O Capacity	Up to 128, 000 I/O points (varies by configuration)
Redundancy	Supported (with specific modules)
Programming Software	Rockwell Automation Studio 5000 Logix Designer
Operating Temperature	0°C to 60°C (32°F to 140°F)
Programming Languages	Ladder Logic, Function Block Diagram, Structured Text, Sequential Function Chart
Modularity	Yes
Certifications	UL, CE
Processor Type	Multiple options available, including standard, safety, and extreme environment processors
Power Supply	Multiple options available, including standard and redundant power supplies with various voltage ranges (e.g., 24V DC, 120/240V AC)
