Allen-Bradley ControlLogix Reference Manual

Interpret the Attribute Tables
Chapter 3
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 105
Attr. ID Access
Rule
Tag Attribute Name B E F P V T C/D Conditional
Implementation
1322 Set Motor Overload Limit - - O O O O Yes
695 Set Motor Overspeed User Limit - - O O O O Yes
694 Set Motor Phase Loss Limit - - O O O O Yes V26
1317 Set Motor Polarity - - O O O O Yes
1319 Set Motor Rated Continuous Current - - R R R R Yes
1321 Set Motor Rated Output Power - - C C C C Yes O-PM; R-IM
1320 Set Motor Rated Peak Current - - C C C C Yes R-PM; O-IM
1318 Set Motor Rated Voltage - - R R R R Yes
1000 Get Motor Test Bus Overvoltage Speed - - R R R R IPM Motor Only, V29
1001 Get Motor Test Commutation Offset Comp - - R R R R IPM Motor Only, V29
174 Get Motor Test Counter EMF - - R R R R PM Motor only
172 Get Motor Test Flux Current - - R R R R Ind Motor only
171 Get Motor Test Inductance - - R R R R
999 Get Motor Test Ld Flux Saturation - - R R R R IPM Motor Only, V29
997 Get Motor Test Ld Inductance - - R R R R IPM Motor Only, V29
998 Get Motor Test Lq Flux Saturation - - R R R R IPM Motor Only, V29
996 Get Motor Test Lq Inductance - - R R R R IPM Motor Only, V29
170 Get Motor Test Resistance - - R R R R
173 Get Motor Test Slip Speed - - R R R R Ind Motor only
175 Get Motor Test Status - - R R R R
697 Set Motor Thermal Overload User Limit - - O O O O Yes
1315 Set Motor Type - - R R R R Yes Optional Enumeration
1316 Set Motor Unit - - R R R R Yes
1325 Set Motor Winding To Ambient Capacitance - - O O O O Yes
1326 Set Motor Winding To Ambient Resistance - - O O O O Yes
521 Get T Operative Current Limit - - O O O O Yes F Support in V29
14 Get Output Cam Execution Targets - R R R R R E
38 Get T Output Cam Lock Status - R - R R R E
37 Get T Output Cam Pending Status - R - R R R E
36 Get T Output Cam Status - R - R R R E
39 Get T Output Cam Transition Status - R - R R R E
601 Get T Output Current - - R R R R Yes
600 Get T Output Frequency - - R O O O Yes
603 Get T Output Power - - R R R R Yes
602 Get T Output Voltage - - R R R R Yes
508 Set Overtorque Limit - - O O O O Yes
509 Set Overtorque Limit Time - - O O O O Yes
1082 Get Planner Actual Position - R R R R R V30
1081 Get Planner Command Position - Fractional - - R R R - V30
1080 Get Planner Command Position - Integer - - R R R - V30

Allen-Bradley ControlLogix Specifications

General

Communication	EtherNet/IP, ControlNet, DeviceNet, DH+
I/O Capacity	Up to 128, 000 I/O points (varies by configuration)
Redundancy	Supported (with specific modules)
Programming Software	Rockwell Automation Studio 5000 Logix Designer
Operating Temperature	0°C to 60°C (32°F to 140°F)
Programming Languages	Ladder Logic, Function Block Diagram, Structured Text, Sequential Function Chart
Modularity	Yes
Certifications	UL, CE
Processor Type	Multiple options available, including standard, safety, and extreme environment processors
Power Supply	Multiple options available, including standard and redundant power supplies with various voltage ranges (e.g., 24V DC, 120/240V AC)
