Interpret the Attribute Tables
118 Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018
ID Access
Rule
Attribute Name B E F P V T Conditional Implementation
1475 Set Feedback 2 Resolver Cable Balance
N - N N N RS
1474 Set Feedback 2 Resolver Excitation Frequency
N - N N N RS
1473 Set Feedback 2 Resolver Excitation Voltage
N - N N N RS
1472 Set Feedback 2 Resolver Transformer Ratio
N - N N N RS
1451 Get Feedback 2 Serial Number
O - N N N
1465 Set Feedback 2 Startup Method
R - R R R O-Enum
1 = Absolute (N)
1484 Set Feedback 2 Velocity Filter Bandwidth
N - N N N
2453 Set Feedback 2 Velocity Filter Taps
N - N N N
250 Set Feedback Commutation Aligned
- - N N N O-Enum
2 = Motor Offset (N)
3 = Self-Sense (N)
31 Set* Feedback Configuration
R R R R R O-Enum
0 = No Feedback (V/N)(T/N)
3 = Load Feedback (PVT/N)
4 = Dual Feedback (P/N)
8 = Dual Integrator Feedback (P/N)
708 Set Feedback Data Loss User Limit
N N N N N
706 Set Feedback Noise User Limit
N N N N N
707 Set Feedback Signal Loss User Limit
N N N N N
44 Set Feedback Unit Ratio
- - N N -
871 Set Flux Braking Enable
- N N N N Ind Motor only
528 Get Flux Current Error
- - N N N
530 Get Flux Current Feedback
- - N N N
525 Get Flux Current Reference
- - N N N
557 Set Flux Integral Time Constant
- - N N N
556 Set Flux Loop Bandwidth
- - N N N
558 Set Flux Up Control
- N N N N Ind Motor only O-Enum
1 = Manual Delay (N)
2 = Automatic Delay (N)
559 Set Flux Up Time
- N N N N Ind Motor only
380 Set Flying Start Enable
- N - N -
570 Set Frequency Control Method
- R - - - O-Enum
128 = Fan/Pump Volts/Hertz (N)
129 = Sensorless Vector (N)
130 = Sensorless Vector Economy (N)
498 Set Friction Compensation Sliding
- - N N N
499 Set Friction Compensation Static
- - N N N
500 Set Friction Compensation Viscous
- - N N N
826/421 Set Friction Compensation Window
- - N - -
981/243 Get Guard Faults
- N N N N
980/242 Get Guard Status
- N Y Y Y
