Allen-Bradley ControlLogix Reference Manual

Interpret the Attribute Tables
Chapter 3
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 125
ID Access
Rule
Attribute B E F P V T Conditional Implementation
2454 Set Feedback 2 Accel Filter Taps N - N N N
2455 Set Feedback 2 Battery Absolute N - N N N TM
1471 Set Feedback 2 Data Code N - N N N TP,SS
1470 Set Feedback 2 Data Length N - N N N TP,SS
2450 Set Feedback 2 Loss Action N - N N N O-Enum
1 = Switch to Sensorless Fdbk (N) 2 = Switch to Redundant
Fdbk (N)
1464 Set Feedback 2 Polarity N - N N N
1475 Set Feedback 2 Resolver Cable Balance N - N N N RS
1474 Set Feedback 2 Resolver Excitation Frequency N - N N N RS
1473 Set Feedback 2 Resolver Excitation Voltage N - N N N RS
1472 Set Feedback 2 Resolver Transformer Ratio N - N N N RS
1451 Get Feedback 2 Serial Number N - N N N
1465 Set Feedback 2 Startup Method R - R R R O-Enum
1 = Absolute (N)
1484 Set Feedback 2 Velocity Filter Bandwidth N - N N N
2453 Set Feedback 2 Velocity Filter Taps N - N N N
250 Set Feedback Commutation Aligned - - Y Y Y O-Enum
2 = Motor Offset (Y) 3 = Self-Sense (N)
4 = Database Offset (N) Vxx
31 Set* Feedback Configuration R R R R R R O-Enum
0 = No Feedback (V/Y)(T/N)
3 = Load Feedback (P/N)(V/N)(T/N) 4 = Dual Feedback (P/N)
8 = Dual Integrator Feedback (P/N)
708 Set Feedback Data Loss User Limit Y Y Y Y Y
706 Set Feedback Noise User Limit N N N N N
707 Set Feedback Signal Loss User Limit N N N N N
44 Set Feedback Unit Ratio - - N N -
871 Set Flux Braking Enable - N N N N Ind Motor only
528 Get Flux Current Error - - Y Y Y
530 Get Flux Current Feedback - - Y Y Y
525 Get Flux Current Reference - - Y Y Y
557 Set Flux Integral Time Constant - - N N N
556 Set Flux Loop Bandwidth - - N N N
558 Set Flux Up Control - Y Y Y Y Ind Motor only O-Enum
1 = Manual Delay (Y)
2 = Automatic Delay (Y)
559 Set Flux Up Time - Y Y Y Y Ind Motor only
380 Set Flying Start Enable - N - N -
381 Set Flying Start Method - N - N - 0-Enum: V29
1 = Counter EMF (N)
2 = Sweep Frequency (N)

Allen-Bradley ControlLogix Specifications

General

Communication	EtherNet/IP, ControlNet, DeviceNet, DH+
I/O Capacity	Up to 128, 000 I/O points (varies by configuration)
Redundancy	Supported (with specific modules)
Programming Software	Rockwell Automation Studio 5000 Logix Designer
Operating Temperature	0°C to 60°C (32°F to 140°F)
Programming Languages	Ladder Logic, Function Block Diagram, Structured Text, Sequential Function Chart
Modularity	Yes
Certifications	UL, CE
Processor Type	Multiple options available, including standard, safety, and extreme environment processors
Power Supply	Multiple options available, including standard and redundant power supplies with various voltage ranges (e.g., 24V DC, 120/240V AC)
