Allen-Bradley ControlLogix Reference Manual

Interpret the Attribute Tables
Chapter 3
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 127
ID Access
Rule
Attribute B E F P V T Conditional Implementation
1310/251 Set Motor Catalog Number - N Y Y Y Dr NV
1313 Set Motor Data Source - R R R R O-Enum
1 = Database (Y) 2 = Drive NV (N) 3 = Motor NV (Y)
1323 Set Motor Integral Thermal Switch - Y5 Y Y Y
1324 Set Motor Max Winding Temperature - Y5 Y Y Y
646 Set Motor Overload Action - Y Y Y Y O-Enum
1 = Current Foldback (Y)
1322 Set Motor Overload Limit - Y Y Y Y
695 Set Motor Overspeed User Limit - Y5 Y Y Y
694 Set Motor Phase Loss Limit - N N N N V26/V27
1317 Set Motor Polarity - Y Y Y Y
1321 Set Motor Rated Output Power - Y Y Y Y O-PM
1320 Set Motor Rated Peak Current - Y5 Y Y Y O-IM
697 Set Motor Thermal Overload User Limit - Y Y Y Y
1001 Get Motor Test Comm Offset Comp - R R R R IPM Motor Only, V29
999 Get Motor Test Ld Flux Saturation - R R R R IPM Motor Only, V29
997 Get Motor Test Ld Inductance - R R R R IPM Motor Only, V29
998 Gett Motor Test Lq Flux Saturation - R R R R IPM Motor Only, V29
996 Get Motor Test Lq Inductance - R R R R IPM Motor Only, V29
1000 Get Motor Test Max Speed - R R R R IPM Motor Only, V29
1315 Set Motor Type - R R R R O-Enum
1 = Rotary Permanent Magnet (Y) 2 = Rotary Induction (Y)
3 = Linear Permanent Magnet (N) 4 = Linear Induction (N)
1325 Set Motor Winding to Ambient Capacitance - Y5 Y Y Y
1326 Set Motor Winding to Ambient Resistance - Y5 Y Y Y
521 Get Operative Current Limit - Y7 Y Y Y F Support in V29
600 Get Output Frequency - R Y Y Y
508 Set Overtorque Limit - N Y Y Y
509 Set Overtorque Limit Time - N Y Y Y
1355 Set PM Motor Extended Speed Permissive N N N V29
2310 Set PM Motor Flux Saturation - N Y Y Y SPM Motor only
1343 Set PM Motor Force Constant - N Y Y Y Rotary PM Motor only
2315 Set PM Motor Ld Flux Saturation N N N N IPM Motor only, V29
1358 Set PM Motor Linear Bus Overvoltage Speed - - N N N V29
1359 Set PM Motor Linear Max Extended Speed - - N N N V29
2314 Set PM Motor Lq Flux Saturation N N N N IPM Motor only, V29
1342 Set PM Motor Rated Force - N Y Y Y Rotary PM Motor only
1339 Set PM Motor Rated Torque - N Y Y Y Rotary PM Motor only
1356 Set PM Motor Rotary Bus Overvoltage Speed - - N N N V29
1357 Set PM Motor Rotary Max Extended Speed - - N N N V29
1340 Set PM Motor Torque Constant - N Y Y Y Rotary PM Motor only

Allen-Bradley ControlLogix Specifications

General

Communication	EtherNet/IP, ControlNet, DeviceNet, DH+
I/O Capacity	Up to 128, 000 I/O points (varies by configuration)
Redundancy	Supported (with specific modules)
Programming Software	Rockwell Automation Studio 5000 Logix Designer
Operating Temperature	0°C to 60°C (32°F to 140°F)
Programming Languages	Ladder Logic, Function Block Diagram, Structured Text, Sequential Function Chart
Modularity	Yes
Certifications	UL, CE
Processor Type	Multiple options available, including standard, safety, and extreme environment processors
Power Supply	Multiple options available, including standard and redundant power supplies with various voltage ranges (e.g., 24V DC, 120/240V AC)
