Allen-Bradley ControlLogix Reference Manual

Interpret the Attribute Tables
Chapter 3
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 137
ID Access
Rule
Attribute B E F P V T Conditional Implementation
1333 Set Rotary Motor Damping Coefficient - N N N N Rotary Motor only
2312 Set Rotary Motor Fan Cooling Derating - N N N N Rotary Motor only
2311 Set Rotary Motor Fan Cooling Speed - N N N N Rotary Motor only
1330 Set Rotary Motor Inertia - N Y Y Y Rotary Motor only
1332 Set Rotary Motor Max Speed - Y Y Y Y Rotary Motor only
765 Set Safe Torque Off Action - N N N N 0-Enum
1 = Current Decel Disable (F/N)
2 = Ramped Decel Disable (FV/N)
128 = DC Injection Brake (FPVT/N)
129 = AC Injection Brake (FPVT/N)
629 Set Shutdown Action N - N N N N O-Enum
1 = Drop DC Bus (FPVT/N)
370 Set Skip Speed 1 - Y - - -
371 Set Skip Speed 2 - Y - - -
372 Set Skip Speed 3 - N - - -
373 Set Skip Speed Band - Y - - -
833 Set SLAT Configuration - - - Y -
834 Set SLAT Set Point - - - Y -
835 Set SLAT Time Delay - - - Y -
610 Set Stopping Action - R R R R O-Enum
1 = Current Decel Disable (F/Y) V26/V27
2 = Ramped Decel Disable (FV/N)
3 = Current Decel Hold (PV/Y)
4 = Ramped Decel Hold (V/N)
128 = DC Injection Brake (FPVT/N)
129 = AC Injection Brake (FPVT/N)
612 Set Stopping Time Limit - Y7 Y Y Y F Support in V29
496 Set System Inertia - - R R N
555 Set Torque Integral Time Constant - - N N N
827 Set Torque Lead Lag Filter Bandwidth - - Y Y Y
828 Set Torque Lead Lag Filter Gain - - Y Y Y
554 Set Torque Loop Bandwidth - - Y Y Y
502 Set Torque Low Pass Filter Bandwidth - - Y Y Y
843 Get
Torque Low Pass Filter Bandwidth
Estimate
- - Y Y Y V26/V27
503 Set Torque Notch Filter Frequency - - Y Y Y
841 Get Torque Notch Filter Frequency Estimate - - Y Y Y V26/V27
837 Set Torque Notch Filter High Frequency Limit - - Y Y Y V26/V27
838 Set Torque Notch Filter Low Frequency Limit - - Y Y Y V26/V27
842 Get Torque Notch Filter Magnitude Estimate - - Y Y Y V26/V27
839 Set Torque Notch Filter Tuning Threshold - - Y Y Y V26/V27
591 Set Torque Prove Current - Y5 Y Y Y V26/V27
506 Set Torque Rate Limit - - Y Y Y

Allen-Bradley ControlLogix Specifications

General

Communication	EtherNet/IP, ControlNet, DeviceNet, DH+
I/O Capacity	Up to 128, 000 I/O points (varies by configuration)
Redundancy	Supported (with specific modules)
Programming Software	Rockwell Automation Studio 5000 Logix Designer
Operating Temperature	0°C to 60°C (32°F to 140°F)
Programming Languages	Ladder Logic, Function Block Diagram, Structured Text, Sequential Function Chart
Modularity	Yes
Certifications	UL, CE
Processor Type	Multiple options available, including standard, safety, and extreme environment processors
Power Supply	Multiple options available, including standard and redundant power supplies with various voltage ranges (e.g., 24V DC, 120/240V AC)
