Allen-Bradley ControlLogix Reference Manual

Interpret the Attribute Tables
Chapter 3
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 141
ID Access Rule Attribute Name B E F P V T Conditional Implementation
2336 Get DC Bus Output Voltage Reference 1 N - N N N N Vxx
2356 Get DC Bus Output Voltage Reference 2 N - N N N N Vxx
870 Set DC Injection Brake Current - - N N N N
872 Set DC Injection Brake Time - - N N N N
486 Set Deceleration Limit - - Y Y Y Y
730 Get Digital Inputs N - N N N N
731 Set Digital Outputs N - N N N N
1435 Set Feedback 1 Accel Filter Bandwidth - Y - Y Y Y
2404 Set Feedback 1 Accel Filter Taps - Y - Y Y Y
2405 Set Feedback 1 Battery Absolute - N - N N N TM
1421 Set Feedback 1 Data Code - N - N N N TP,SS
1420 Set Feedback 1 Data Length - N - N N N TP,SS
2400 Set Feedback 1 Loss Action - N - N N N O-Enum
1 = Switch to Sensorless Fdbk (N)
2 = Switch to Redundant Fdbk (N)
1414 Set Feedback 1 Polarity - Y - Y Y Y
1425 Set Feedback 1 Resolver Cable Balance - N - N N N RS
1424 Set
Feedback 1 Resolver Excitation
Frequency
- N - N N N RS
1423 Set
Feedback 1 Resolver Excitation
Voltage
- N - N N N RS
1422 Set
Feedback 1 Resolver Transformer
Ratio
- N - N N N RS
1401 Get Feedback 1 Serial Number - Y - Y Y Y
1415 Set Feedback 1 Startup Method - R - R R R O-Enum
1 = Absolute (Y)
1434 Set
Feedback 1 Velocity Filter Bandwidth
- Y - Y Y Y
2403 Set Feedback 1 Velocity Filter Taps - Y - Y Y Y
1485 Set Feedback 2 Accel Filter Bandwidth - Y - Y Y Y
2454 Set Feedback 2 Accel Filter Taps - Y - Y Y Y
2455 Set Feedback 2 Battery Absolute - N - N N N TM
1471 Set Feedback 2 Data Code - N - N N N TP,SS
1470 Set Feedback 2 Data Length - N - N N N TP,SS
2450 Set Feedback 2 Loss Action - N - N N N O-Enum
1 = Switch to Sensorless Fdbk (N)
2 = Switch to Redundant Fdbk (N)
1464 Set Feedback 2 Polarity - Y - Y Y Y
1475 Set Feedback 2 Resolver Cable Balance - N - N N N RS
1474 Set
Feedback 2 Resolver Excitation
Frequency
- N - N N N RS
1473 Set
Feedback 2 Resolver Excitation
Voltage
- N - N N N RS
1472 Set
Feedback 2 Resolver Transformer
Ratio
- N - N N N RS
