Allen-Bradley ControlLogix Reference Manual

Chapter 3
Interpret the Attribute Tables
140 Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018
ID Access Rule Attribute Name B E F P V T Conditional Implementation
2338 Get
Bus Output Overvoltage Factory
Limit 1
N - N N N N Vxx
2358 Get
Bus Output Overvoltage Factory
Limit 2
N - N N N N Vxx
2339 Get
Bus Output Undervoltage Factory
Limit 1
N - N N N N Vxx
2359 Get
Bus Output Undervoltage Factory
Limit 2
N - N N N N Vxx
638/262 Get Bus Regulator Capacity N - N N N N
659 Get CIP Axis Alarms N Y Y Y Y Y
904 Get CIP Axis Alarms - RA N Y Y Y Y Y
617 Set Coasting Time Limit - - Y Y Y Y V26/V27
850 Set Commutation Offset Compensation - - N N N PM Motor only, V29
563 Set Commutation Polarity - - - Y Y Y PM Motor only
562 Set Commutation Self-Sensing Current - - - N N N PM Motor only
618 Set Connection Loss Stopping Action - - Y Y Y Y O-Enum V31
1 = Current Decel Disable (F/Y)
2 = Ramped Decel Disable (FV/Y)
3 = Current Decel Hold (PV/N)
4 = Ramped Decel Hold (V/N)
637 Get Converter Capacity N - N N N N
2337 Get Converter Output Capacity 1 N - N N N N Vxx
2357 Get Converter Output Capacity 2 N - N N N N Vxx
605 Get Converter Output Current N - N N N N V26/V27
2330 Get Converter Output Current 1 N - N N N N Vxx
2350 Get Converter Output Current 2 N - N N N N Vxx
606 Get Converter Output Power N - N N N N V26/V27
2331 Get Converter Output Power 1 N - N N N N Vxx
2351 Get Converter Output Power 2 N - N N N N Vxx
2332 Get Converter Output Rated Current 1 N - N N N N Vxx
2352 Get Converter Output Rated Current 2 N - N N N N Vxx
2333 Get Converter Output Rated Power 1 N - N N N N Vxx
2353 Get Converter Output Rated Power 2 N - N N N N Vxx
840 Set Current Disturbance - - - N N N
527 Get Current Error - - - Y Y Y
529 Get Current Feedback - - - Y Y Y
522 Get Current Limit Source - - Y7 Y Y Y (F/V29)
524 Get Current Reference - - - Y Y Y
553 Set Current Vector Limit - - Y Y Y Y
2334 Get DC Bus Output Voltage 1 N - N N N N Vxx
2354 Get DC Bus Output Voltage 2 N - N N N N Vxx
742 Get DC Bus Output Voltage Reference N - N N N N Vxx

Allen-Bradley ControlLogix Specifications

General

Communication	EtherNet/IP, ControlNet, DeviceNet, DH+
I/O Capacity	Up to 128, 000 I/O points (varies by configuration)
Redundancy	Supported (with specific modules)
Programming Software	Rockwell Automation Studio 5000 Logix Designer
Operating Temperature	0°C to 60°C (32°F to 140°F)
Programming Languages	Ladder Logic, Function Block Diagram, Structured Text, Sequential Function Chart
Modularity	Yes
Certifications	UL, CE
Processor Type	Multiple options available, including standard, safety, and extreme environment processors
Power Supply	Multiple options available, including standard and redundant power supplies with various voltage ranges (e.g., 24V DC, 120/240V AC)
