Interpret the Attribute Tables
Chapter 3
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 151
ID Access Rule Attribute Name B E F P V T Conditional Implementation
31 Set* Feedback Configuration R R R R R R O-Enum
0 = No Feedback (V/N)(T/N)
3 = Load Feedback (P/Y)(V/Y)(T/N)
4 = Dual Feedback (P/Y)
8 = Dual Integrator Feedback (P/N)
708 Set Feedback Data Loss User Limit - Y Y Y Y Y
706 Set Feedback Noise User Limit - Y Y Y Y Y
707 Set Feedback Signal Loss User Limit - Y Y Y Y Y
44 Set Feedback Unit Ratio - - - Y Y -
871 Set Flux Braking Enable - - N N N N Ind Motor only
528 Get Flux Current Error - - - Y Y Y
530 Get Flux Current Feedback - - - Y Y Y
525 Get Flux Current Reference - - - Y Y Y
557 Set Flux Integral Time Constant - - - N N N
556 Set Flux Loop Bandwidth - - - N N N
558 Set Flux Up Control - - Y Y Y Y Ind Motor only
O-Enum
1 = Manual Delay (Y)
2 = Automatic Delay (Y)
559 Set Flux Up Time - - Y Y Y Y Ind Motor only
380 Set Flying Start Enable - - N - Y -
381 Set Flying Start Method - - N - Y - O-Enum: V29
1 = Counter EMF (N)
2 = Sweep Frequency (N)
570 Set Frequency Control Method - - R - - - O-Enum
128 = Fan/Pump Volts/Hertz (Y)
129 = Sensorless Vector (Y)
130 = Sensorless Vector Economy (N)
498 Set Friction Compensation Sliding - - - Y Y Y
499 Set Friction Compensation Static - - - Y Y Y
500 Set Friction Compensation Viscous - - - Y Y Y
826/421 Set Friction Compensation Window - - - Y - -
981/243 Get Guard Faults - - Y Y Y Y
980/242 Get Guard Status - - Y Y Y Y
280 Set Home Torque Threshold - - - N N - Vxx
281 Set Home Torque Time - - - N N - Vxx
1349 Set
Induction Motor Magnetization
Reactance
- - N N N N Ind Motor only
1352 Set Induction Motor Rated Slip Speed - - Y Y Y Y Ind Motor only
1351 Set
Induction Motor Rotor Leakage
Reactance
- - Y Y Y Y Ind Motor only, V26/V27
1350 Set Induction Motor Rotor Resistance - - N N N N Ind Motor only
1348 Set
Induction Motor Stator Leakage
Reactance
- - Y Y Y Y Ind Motor only, V26/V27
