Allen-Bradley ControlLogix Reference Manual

Chapter 3
Interpret the Attribute Tables
160 Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018
ID Access Rule Attribute Name B E F P V T Conditional Implementation
2310 Set PM Motor Flux Saturation - N Y Y Y PM Motor only
1343 Set PM Motor Force Constant - N Y Y Y Rotary PM Motor only
1342 Set PM Motor Rated Force - N Y Y Y Rotary PM Motor only
1339 Set PM Motor Rated Torque - N Y Y Y Rotary PM Motor only
1340 Set PM Motor Torque Constant - N Y Y Y Rotary PM Motor only
445 Set Position Error Tolerance Time - - Y - -
365 Get Position Fine Command - - Y - -
446 Set Position Integrator Control - - R - - O-Bits
1: Auto-Preset (N)
447 Set Position Integrator Preload - - N - -
781 Set Position Lead Lag Filter Bandwidth - - Y - -
782 Set Position Lead Lag Filter Gain - - Y - -
783 Set Position Notch Filter Frequency - - Y - -
627 Set Power Loss Action - N N N N O-Enum
1 = Coast Thru (N)
2 = Decel Regen (N)
628 Set Power Loss Threshold - N N N N
630 Set Power Loss Time - N N N N
376 Set* Ramp Acceleration - N - N - Derived
377 Set* Ramp Deceleration - N - N - Derived
378 Set Ramp Jerk Control - N - N -
375 Set* Ramp Velocity - Negative - N - N - Derived
374 Set* Ramp Velocity - Positive - N - N - Derived
613/354 Set Resistive Brake Contact Delay - N Y Y Y PM Motor only
1333 Set Rotary Motor Damping Coefficient - N N N N Rotary Motor only
2312 Set Rotary Motor Fan Cooling Derating - N N N N Rotary Motor only
2311 Set Rotary Motor Fan Cooling Speed - N N N N Rotary Motor only
1330 Set Rotary Motor Inertia - N Y Y Y Rotary Motor only
1332 Set Rotary Motor Max Speed - N Y Y Y Rotary Motor only
629 Set Shutdown Action - N Y Y Y O-Enum
1 = Drop DC Bus (Y)
370 Set Skip Speed 1 - N - - -
371 Set Skip Speed 2 - N - - -
372 Set Skip Speed 3 - N - - -
373 Set Skip Speed Band - N - - -
833 Set SLAT Configuration - - - N -
834 Set SLAT Set Point - - - N -
835 Set SLAT Time Delay - - - N -
