Interpret the Attribute Tables
Chapter 3
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 171
ID Access Attribute B E F P V T Conditional Implementation
871 Set Flux Braking Enable - Y Y Y Y Ind Motor only
528 Get Flux Current Error - - N N N
530 Get Flux Current Feedback - - Y Y Y
525 Get Flux Current Reference - - N N N
557 Set Flux Integral Time Constant - - N N N
556 Set Flux Loop Bandwidth - - N N N
558 Set Flux Up Control - Y Y Y Y Ind Motor only, O-Enum
1 = Manual Delay (Y)
2 = Automatic Delay (Y)
559 Set Flux Up Time - Y Y Y Y Ind Motor only
380 Set Flying Start Enable - Y - Y -
570 Set Frequency Control Method - R - - - O-Enum
128 = Fan/Pump Volts/Hertz (Y)
129 = Sensorless Vector (Y)
130 = Sensorless Vector Economy (Y)
498 Set Friction Compensation Sliding - - N N N
499 Set Friction Compensation Static - - N N N
500 Set Friction Compensation Viscous - - N N N
826/421 Set Friction Compensation Window - - N - -
981/243 Get Guard Faults - N N N N
980/242 Get Guard Status - N N N N
1349 Set Induction Motor Magnetization Reactance - N N N N Ind Motor only
1352 Set Induction Motor Rated Slip Speed - Y Y Y N Ind Motor only
1350 Set Induction Motor Rotor Resistance - N N N N Ind Motor only
647 Set Inverter Overload Action - Y Y Y Y O-Enum
1 = Current Foldback (Y)
128 = Reduce PWM Rate (Y)
129 = PWM Foldback (Y)
699 Set Inverter Thermal Overload User Limit - N N N N
1338 Set Linear Motor Damping Coefficient - N N N N Linear Motor only
2313 Set Linear Motor Integral Limit Switch - N N N N Linear Motor only
1336 Set Linear Motor Mass - N N N N Linear Motor only
1337 Set Linear Motor Max Speed - N N N N Linear Motor only
801 Get Load Observer Acceleration Estimate - - Y Y N
806 Set Load Observer Bandwidth - - Y Y N
805 Set Load Observer Configuration - - Y Y N O-Enum
1 = Load Observer Only (Y)
2 = Load Observer with Velocity Estimate (N)
3 = Velocity Estimate Only (N)
4 = Acceleration Feedback (Y)
809 Set Load Observer Feedback Gain - - Y Y N
807 Set Load Observer Integrator Bandwidth - - N N N
802 Get Load Observer Torque Estimate - - Y Y N
