Allen-Bradley ControlLogix Reference Manual

Interpret the Attribute Tables
Chapter 3
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 177
ID Access
Rule
Attribute B E F P V T Conditional Implementation
250 Set Feedback Commutation Aligned - - Y Y Y O-Enum
2 = Motor Offset (N)
3 = Self-Sense (Y)
31 Set Feedback Configuration R R R R R O-Enum
0 = No Feedback (V/Y)(T/Y)
3 = Load Feedback (PVT/N)
4 = Dual Feedback (P/Y)
8 = Dual Integrator Feedback (P/Y)
708 Set Feedback Data Loss User Limit N N N N N
706 Set Feedback Noise User Limit N N N N N
707 Set Feedback Signal Loss User Limit N N N N N
44 Set Feedback Unit Ratio - - Y N -
871 Set Flux Braking Enable - Y Y Y Y Ind Motor only
528 Get Flux Current Error - - N N N
530 Get Flux Current Feedback - - Y Y Y
525 Get Flux Current Reference - - N N N
557 Set Flux Integral Time Constant - - N N N
556 Set Flux Loop Bandwidth - - N N N
558 Set Flux Up Control - Y Y Y Y Ind Motor only O-Enum
1 = Manual Delay (Y)
2 = Automatic Delay (Y)
559 Set Flux Up Time - Y Y Y Y Ind Motor only
380 Set Flying Start Enable - Y - Y -
570 Set Frequency Control Method - R - - - O-Enum
128 = Fan/Pump Volts/Hertz (Y) 129 =
Sensorless Vector (Y)
130 = Sensorless Vector Economy (Y)
498 Set Friction Compensation Sliding - - N N N
499 Set Friction Compensation Static - - N N N
500 Set Friction Compensation Viscous - - N N N
826/421 Set Friction Compensation Window - - N - -
981/243 Get Guard Faults - Y Y Y Y
980/242 Get Guard Status - Y Y Y Y
1349 Set Induction Motor Magnetization Reactance - N N N N Ind Motor only
1352 Set Induction Motor Rated Slip Speed - Y Y Y N Ind Motor only
1350 Set Induction Motor Rotor Resistance - N N N N Ind Motor only
647 Set Inverter Overload Action - Y Y Y Y O-Enum
1 = Current Foldback (Y)
128 = Reduce PWM Rate (Y)
129 = PWM Foldback (Y)
699 Set Inverter Thermal Overload User Limit - N N N N
1338 Set Linear Motor Damping Coefficient - N N N N Linear Motor only
2313 Set Linear Motor Integral Limit Switch - N N N N Linear Motor only

Allen-Bradley ControlLogix Specifications

General

Communication	EtherNet/IP, ControlNet, DeviceNet, DH+
I/O Capacity	Up to 128, 000 I/O points (varies by configuration)
Redundancy	Supported (with specific modules)
Programming Software	Rockwell Automation Studio 5000 Logix Designer
Operating Temperature	0°C to 60°C (32°F to 140°F)
Programming Languages	Ladder Logic, Function Block Diagram, Structured Text, Sequential Function Chart
Modularity	Yes
Certifications	UL, CE
Processor Type	Multiple options available, including standard, safety, and extreme environment processors
Power Supply	Multiple options available, including standard and redundant power supplies with various voltage ranges (e.g., 24V DC, 120/240V AC)
