Allen-Bradley ControlLogix Reference Manual

CIP Axis Attributes
Chapter 4
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 215
Torque Limit - Negative
Usage Access T Data
Type
Default Min Max Semantics of Values
Required - C Set/SSV REAL -100
FD
-10
3
0 % Motor Rated
This negative value determines the most negative torque value that can be applied
to the motor. If the device attempts to apply a more negative torque than this
limit, the torque command is clamped to this value.
Torque Rate Limit
Usage Access T Data
Type
Default Min Max Semantics of Values
Optional - C Set/SSV REAL 10
6
0
% Motor Rated / Sec
Limits the rate of change of the torque reference signal.
Torque Threshold
Usage Access T Data
Type
Default Min Max Semantics of Values
Optional - C Set/SSV REAL 90
FD
0 10
3
% Motor Rated
Specifies the threshold for the Filtered Torque Reference signal magnitude that
when exceeded, results in the Torque Threshold status bit being set.
Overtorque Limit
Usage Access T Data
Type
Default Min Max Semantics of Values
Optional - D Set/SSV REAL 200 0 10
3
% Motor Rated
Maximum limit for the torque producing Iq Current Feedback signal magnitude.
When the Iq Current Feedback signal is greater than this value for the duration
specified by Overtorque Limit Time attribute, the result is an Overtorque Limit
exception. This feature lets the device generate an exception if there is a sudden
increase in load torque during operation. This condition could occur if a bearing
fails, a hard stop is reached, or there is some other mechanical failure.

Allen-Bradley ControlLogix Specifications

General

Communication	EtherNet/IP, ControlNet, DeviceNet, DH+
I/O Capacity	Up to 128, 000 I/O points (varies by configuration)
Redundancy	Supported (with specific modules)
Programming Software	Rockwell Automation Studio 5000 Logix Designer
Operating Temperature	0°C to 60°C (32°F to 140°F)
Programming Languages	Ladder Logic, Function Block Diagram, Structured Text, Sequential Function Chart
Modularity	Yes
Certifications	UL, CE
Processor Type	Multiple options available, including standard, safety, and extreme environment processors
Power Supply	Multiple options available, including standard and redundant power supplies with various voltage ranges (e.g., 24V DC, 120/240V AC)
