Allen-Bradley ControlLogix Reference Manual

CIP Axis Attributes
Chapter 4
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 307
Feedback Mode SSV Promotion Rules
The following table describes valid Feedback Modes.
Feedback Configuration Valid Feedback Modes
No Feedback No Feedback
Master Feedback Master Feedback
Motor Feedback Motor Feedback
No Feedback
Load Feedback Load Feedback
Dual Feedback
Motor Feedback
No Feedback
Dual Feedback Dual Feedback
Load Feedback
Motor Feedback
No Feedback
Feedback Unit Ratio
Usage Access Data
Type
Default Min Max Semantics of Values
Optional - E
PV only
Set/GSV REAL 1
FD
- - Feedback 1 Units per Feedback 2 Unit
The Feedback Unit Ratio attribute is the number of Feedback 1 Units per
Feedback 2 Unit. This value is also used by the drive to convert between feedback
2 counts to feedback 1 counts when configured for load feedback or dual feedback
operation.
Feedback n Unit
Usage Access Data
Type
Default Min Max Semantics of Values
Required - E Set/GSV USINT 0
DB
- - Enumeration
0 = Rev
1 = Meter
2...127 = Reserved
128...255 = Vendor
The Feedback n Unit attribute is a unit of measure for the designated feedback
device. The Feedback Unit for Feedback 1 and any redundant feedback device for
Feedback 1 must be scalable to the configured Motor Unit; if the Motor Unit is
set to Rev, Feedback 1 Unit must be set to Rev; if Motor Unit is set to Meter,
Feedback 1 Unit will be set to Meter. Feedback devices with a Feedback Unit of
Rev are considered "rotary" devices, while Feedback devices with a Feedback unit
of Meter are considered "linear" devices.
