Allen-Bradley Kinetix 350 User Manual

Rockwell Automation Publication 2097-UM002D-EN-P - April 2017 13
Start Chapter 1
Figure 1 - Typical Kinetix 350 Drive Installation
(1) See Ethernet Cable Connections on page 74 for information on how to use an unmanaged switch in your application.
2097-V3xxxx-LM
Kinetix 350 Drive
2097-Fx
AC Line Filter (optional equipment)
2097-F1 Filter Shown
Line
Disconnect
Device
Input
Fusing
Three-phase
Input Power
24V DC Control Back-up
Power Supply
(optional equipment)
MP-Series and TL-Series
Rotary Motors
(MPL-Bxxxx motors shown)
Bulletin 2090
Motor Feedback Cables
Bulletin 2090
Motor Power Cables
2097-TB1 Terminal
Expansion Block
2097-Rx
Shunt Resistor
(optional equipment)
MP-Series and TL-Series Electric Cylinders
(MPAR-Bxxxx electric cylinders shown)
MP-Series Integrated Linear Stages
(MPAS-B9xxx ballscrew shown)
MP-Series Heavy-duty Electric Cylinders
(MPAI-Bxxxx electric cylinders shown)
2090-K2CK-D15M
Low-profile Connector Kit

Allen-Bradley Kinetix 350 Specifications

General

Brand	Allen-Bradley
Model	Kinetix 350
Category	Servo Drives
Language	English
