Table 7 - Fuse and Circuit Breaker (CB) Specifications
Drive Cat. No.
Drive
Voltage
Phase
UL Applications IEC (non-UL) Applications
Fuses
(Bussmann)
Cat. No.
Miniature CB
(1)
Cat. No.
Motor
Protection CB,
(1) (2)
Self-protected CMC
Cat. No.
Miniature CB
(1)
Cat. No.
Motor Protection CB
(1)
Cat. No.
2097-V31PR0-LM
120V
Single-phase
(voltage doubler)
KTK-R-20 (20 A) 1489-M1C200 140M-D8E-C20 1489-M1C200 1492-SPM1D200 140M-D8E-C20
120/240V Single-phase KTK-R-10 (10 A) 1489-M1C100 140M-C2E-C10 1489-M1C100 1492-SPM1D100 140M-C2E-C10
2097-V31PR2-LM
120V
Single-phase
(voltage doubler)
KTK-R-30 (30 A) 1489-M1C300 140M-F8E-C32 1489-M1C300 1492-SPM1D300 140M-F8E-C32
120/240V Single-phase KTK-R-20 (20 A) 1489-M1C200 140M-D8E-C20 1489-M1C200 1492-SPM1D200 140M-D8E-C20
2097-V32PR0-LM
240V Single-phase
KTK-R-20 (20 A) 1489-M1C150 140M-D8E-C16 1489-M1C150 1492-SPM1D150 140M-D8E-C16
2097-V32PR2-LM KTK-R-20 (20 A) 1489-M1C200 140M-D8E-C20 1489-M1C200 1492-SPM1D200 140M-D8E-C20
2097-V32PR4-LM KTK-R-30 (30 A) 1489-M1C300 140M-F8E-C32 1489-M1C300 1492-SPM1D320 140M-F8E-C32
2097-V33PR1-LM
120/240V Single-phase KTK-R-20 (20 A) 1489-M1C200 140M-D8E-C20 1489-M1C200 1492-SPM1D200 140M-D8E-C20
240V Three-phase KTK-R-15 (15 A) 1489-M3C150 140M-D8E-C16 1489-M3C150 1492-SPM3D150 140M-D8E-C16
2097-V33PR3-LM
120/240V Single-phase KTK-R-20 (20 A) 1489-M1C200 140M-D8E-C20 1489-M1C200 1492-SPM1D200 140M-D8E-C20
240V Three-phase KTK-R-15 (15 A) 1489-M3C150 140M-D8E-C16 1489-M3C150 1492-SPM3D150 140M-D8E-C16
2097-V33PR5-LM
120/240V Single-phase KTK-R-30 (30 A) 1489-M1C300 140M-F8E-C32 1489-M1C300 1492-SPM1D300 140M-F8E-C32
240V Three-phase KTK-R-20 (20 A) 1489-M3C200 140M-D8E-C20 1489-M3C200 1492-SPM3D200 140M-D8E-C20
2097-V33PR6-LM
120/240V Single-phase
LPJ-40SP (40 A)
Class J
N/A
140M-F8E-C32
N/A N/A
140M-F8E-C32
240V Three-phase KTK-R-30 (30 A) 1489-M3C300 1489-M3C300 1492-SPM3D300
2097-V34PR3-LM
480V Three-phase
KTK-R-10 (10 A) 1489-M3C100 140M-C2E-C10 1489-M3C100 1492-SPM3D100 140M-C2E-C10
2097-V34PR5-LM KTK-R-10 (10 A) 1489-M3C100 140M-C2E-C10 1489-M3C100 1492-SPM3D100 140M-C2E-C10
2097-V34PR6-LM KTK-R-20 (20 A) 1489-M3C200 140M-D8E-C20 1489-M3C200 1492-SPM3D200 140M-D8E-C20
(1) Bulletin 1492 and 1489 circuit protection devices have lower short-circuit current ratings than Bulletin 140M devices.
See http://ab.rockwellautomation.com/allenbradley/productdirectory.page?
for product literature with specific short-circuit ratings.
(2) For UL applications, Bulletin 140M devices are applied as self-protected combination motor controllers.
